UAL Innovation
Reshape with LipoSaver
Liposaver is a high definition body sculpting device that is advanced in surgical technique to selectively define targeted areas to achieve a sculpted figure.
UAL Procedure
How Ultrasound LipoSaver Technology works in action
Minimal invasiveness of Liposaver enables high definition liposculpture to safely remove accumulation of both small and large deposits of adipose tissue. Surgeons can experience versatility with excellent outcome and have safe procedure consistently.
Probe
Ultrasound energy is emitted in the designated area previously infiltrated with tumescent fluid.
Ultrasound Energy
The ultrasound energy shifts the tumescent fluid generating thousand of micro-bubbles.
Micro Bubbles
Fatty deposits of micro bubbles then expand and fragment from the surrounding tissues.
Fat Cells
Emulsified cells are mixed with tumescent fluid to be easily extracted in selected process.
UAL Probe
Ideal features for treating all tissue types
LipoSaver is compatible with various probes in size of length, diameter and numboer of grooves designed to treat both soft and fibrous tissues. Availbility of different mode option and power enables high definition sculpted contour of the body.
Power
Length/Diameter
Grooves
N/Z Mode
UAL Advantage
Establishing New Stardard of Liposuction Technology
The new standard set by LipoSaver LS-2000 delivers results that physicians can greatly benefit from this safe and reliable technology.
UAL Benefits
Results that matter
Faster Recovery
Reduced invasiveness of liposuction surgery results in faster recovery with minimalized scarring
Reduced Trauma
Greater tissue selection and less damage to other tissues leads to reduced pain and trauma.
Innovative UAL System
LipoSaver LS-1000
First Model of LipoSaver, LS-1000, focuses on the simplicity of the application to yield satisfying results. It provides consistenet utilization, enabling the surgeons to focus on the procedures.
| Technical Specification | |
|---|---|
Input Power |
AC 100V - 240V / 50 - 60Hz |
Maximum Power Dissipation |
100 VA |
Probe Tuning Frequency Range |
35 kHz - 40 kHz |
Output Acoustic Power |
0 - 90 W max ± 20% |
Operation Modes |
N Mode: Continuous output Z Mode: Pulsed output Duty cycle: 500ms on, 500ms off |
Handpiece |
215mm, 30 ⌀ |
Dimension (W × H × L) |
396 × 170 × 360 mm |
Foot Switch |
10A / 250 |
Fuse |
250 V / 2A, 20mm × 5mm (Diameter: ⌀ ) |
Innovative UAL System
LipoSaver LS-2000
Evolution of LHbiomed's LipoSaver series, LS-2000, improves in probe compatibility for optimised control and accuracy to provide better ergonomics for medical professionals.
| Technical Specification | |
|---|---|
Emulsification Source |
Ultrasonic |
Dimension (W × H × L) |
396 × 170 × 360 mm |
Handpiece |
215mm, 30 ⌀ |
Main Body Weight |
6.5 kg |
Operation Modes |
N Mode: Continuous output Z Mode: Pulsed output (Duty cycle: 66%) |
Probes |
⌀1.9 / ⌀2.9 / ⌀3.7 |
Probe Tuning Frequency |
35 kHz - 40 kHz |
Output Acoustic Power |
0 - 90 W max ± 20% |
Input Power |
AC 100V - 240V / 50 - 60Hz |
